| SPECIFICATIONS | |
| Model No. | E1-M |
| Type | Active full range column speaker |
| Frequency Response (-6dB) | 200 Hz - 21 kHz |
| Max. SPL (1m, free space) | 117 dB |
| Power Output (RMS) | 50W @ 4 ohm |
| Transducer MF | 4 * 2.75", neodymium magnet, 1"voice coil |
| Amplifier | Class-D amplifier |
| Audio / Power Input / Output | Speakon with 4 core ( 2Core 24V / 2Core Signal +/- ) |
| Enclosure | PP Plastic |
| Grille | 1.0mm thickness metal grille without acoustic fabric |
| Dispersion (H * V) | 140° * 30° |
| Model No. | E1-10D |
| Type | 10'' active bass reflex, main subwoofer |
| Frequency Response (-6dB) | 47 Hz - 200 Hz |
| Max. SPL (1m, free space) | 117 dB |
| Power Output (RMS) | 400W |
| Impedance | 4 Ohms |
| Transducer LF | 10"subwoofer, 2.5"voice coil |
| Amplifier | Class-D amplifier |
| DSP Module | LA DSP-100, 96 kHz, 24-bit DSP processor with preset modes: Speech, DJ, Live |
| Protection | Short circuit overheating, over-current |
| Controls | Power On / Off switch, satellite level, subwoofer level, Line/Mic switch, Bluetooth On / Off switch, TWS switch, reset switch, DSP modes switch |
| Indicators | Power, signal, limit, bluetooth, reset |
| Audio Input / Output | Left / Right female and male XLR input, 1 * XLR output, 1* Satellite Speakon output |
| Power Input / Output | Speakon |
| Power Supply | 110~250V 50/60HZ |
| Enclosure | 15mm MDF with regular raindrop painting |
| Grille | Metal grille without acoustic fabric |
| Model No. | E1-10DM |
| Type | 10'' active bass reflex, slave subwoofer |
| Frequency Response (-6dB) | 47 Hz - 200 Hz |
| Max. SPL (1m, free space) | 117 dB |
| Power Output (RMS) | 400W |
| Impedance | 4 Ohms |
| Transducer LF | 10"subwoofer, 2.5"voice coil |
| Amplifier | Class-D amplifier |
| Protection | Short circuit overheating, over-current |
| Controls | Power On / Off switch, main level |
| Indicators | Power, signal, limit |
| Audio Input / Output | 1 * XLR input, 1 * XLR output |
| Power Input / Output | Powercon |
| Power Supply | 110~250V 50/60HZ |
| Enclosure | 15mm MDF with regular raindrop painting |
| Grille | Metal grille without acoustic fabric |
