| Model No. | PEQ-15 | PEQ-15A |
| Type | 15'' 2-way full range speaker, active | |
| Frequency Response (-6dB) | 50 Hz - 20 kHz | |
| Max. SPL (1m, free space) | 129dB | |
| Impedance | 4 Ohms | |
| Transducer LF | 15"woofer, 2.5'' VC,50 Oz | |
| Transducer HF | 1"Ti. tweeter | |
| Enclosure | ABS cabinet, 35mm stand pole, 3 handles and 2 sides | |
| Grille | Metal grille with acoustic fabric | |
| Amplifier | / | Class-AB Mono amplifier |
| Power Output (RMS) | 180W/8Ω | |
| Controls | / | Power On / Off switch, MP3 player, two mic level, line/MP3 level, echo, master level, mic/line switch, 5- band EQ, voltage switch |
| Indicators | / | Power, clip |
| Audio Input / Output | SpeakON | 2 * XLR Mic inputs 1 * Jack Mic input 1 * RCA line input, 1 * AUX line input, 1 * XLR line output, Speakon output Mp3 player with USB+SD+FM+Bluetooth input |
| Power Supply | 100~130V 50/60HZ or 210~250V 50/60HZ | |
