| Model No. | PXL-15 | PXL-15D2 |
| Type | 15'' 2-way full range speaker, passive | 15'' 2-way full range speaker, active |
| Frequency Response (-6dB) | 50 Hz - 20 kHz | |
| Max. SPL(1m, free space) | 129 dB | |
| Impedance | 4Ohms | |
| Transducer LF | 15"woofer, 2.5"voice coil, 80oz | |
| Transducer HF | 1.75'' compression driver | |
| Enclosure | H-PP with painting, 35mm stand pole, 1 top + 2 side handles | |
| Grille | Metal grille with acoustic fabric | |
| Amplifier | / | Class-D BI amplifier |
| Power Output (RMS) | 450W (LF)+50W(HF) | |
| DSP Module | / | LA DSP-200S, 96 kHz, 24-bit DSP processor with LCD display |
| Protection | / | Short circuit overheating, over-current |
| Controls | / | Power On / Off switch, main level, DSP modes switch, two line levels, mic/line switch |
| Indicators | / | Power, limit |
| Audio Input / Output | Speakon | 1 * Combo XLR/Jack input 1 * XLR input 1 * XLR output |
| Optional Funciton | / | Bluetooth |
| Power Supply | 100~130V 50/60HZ 210~250V 50/60HZ | |
