PAZ Series


Model No. PAZ-12D1 PAZ-15D1 PAZ-15SD1 PAZ-18SD1
Type 12'' 2-way full range speaker, active 15'' 2-way full range speaker, active 15'' bass reflex, active 18'' bass reflex, active
Frequency Response (-6dB) 55 Hz - 20 kHz 50 Hz - 20 kHz 50 Hz - 200 Hz 45 Hz - 200 Hz
Max. SPL(1m, free space) 125 dB 129 dB 116 dB 121 dB
Impedance 4Ohms
Transducer LF 12" woofer,2" voice coil, 40oz 15" woofer,2.5" voice coil, 80oz 15" subwoofer Alu frame, 3" KSV voice coil, 70oz 18" subwoofer Alu frame, 3" KSV voice coil, 80oz
Transducer HF 1"Ti.tweeter 1.34"Ti.tweeter /
Enclosure ABS cabinet, 35mm stand pole
4 handles, top and down, 2 sides
18mm MDF with regular painting, Φ35, stand adaptor
Grille Metal grille with acoustic fabric
Amplifier Class-D BI amplifier Class-D amplifier
Power Output (RMS) 350W (LF)+50W(HF) 400W (LF)+50W(HF) 450W 500W
DSP Module LA DSP-100, 96 kHz, 24-bit DSP processor with preset modes: Monitor, DJ, Live
Protection Short circuit overheating, over-current
Controls Power On / Off switch, DSP , mic/line switch Power On / Off switch, DSP modes switch,Subwoofer volume,Phase switch,High pass/Full range switch
Indicators Power, signal, limit, DSP modes Power, signal, limit
Audio Input / Output 2 * Combo XLR/Jack input
1 * XLR input
1 * XLR output
Left / Right XLR line input
Left / Right XLR line output
1 * XLR output
1 * XLR output highpass 120Hz
Power Supply 100~130V 50/60HZ
210~250V 50/60HZ
100~130V 50/60HZ
210~250V 50/60HZ
Model NO.: PAZ-18SD1
Model NO.: PAZ-15SD1
Model NO.: PAZ-12D1
Model NO.: PAZ-15D1
