| Model No. | MK-08D1 | MK-10D1 | MK-12D1 | MK-15D1 |
| Type | 8'' 2-way full range speaker, active |
10'' 2-way full range speaker, active |
12'' 2-way full range speaker, active |
15'' 2-way full range speaker, active |
| Frequency Response (-3dB) |
88 Hz - 20 kHz | 88 Hz - 20 kHz | 59 Hz - 20 kHz | 59 Hz - 20 kHz |
| Max. SPL (1m, free space) |
121 dB | 121 dB | 128 dB | 129 dB |
| Impedance | 4Ohms | |||
| Power Rating | 175W (Cont.) / 350W (PGM) |
200W (Cont.) / 400W (PGM) |
350W (Cont.) / 700W (PGM) |
400W (Cont.) / 800W (PGM) |
| Transducer LF | 8" steel fram woofer, 2" voice coil, 40oz |
10" steel fram woofer, 2" voice coil, 50oz |
12" Aluminium woofer, 3" voice coil, 80oz |
15" Aluminium woofer, 3" voice coil, 90oz |
| Transducer HF | 1.5" polymer driver | |||
| Enclosure | 15mm plywood with regular painting, 35mm stand pole, 1 top handle | |||
| Grille | Metal grille with acoustic fabric | |||
| Amplifier | Class-D BI amplifier | |||
| Power Output (RMS) | 160W(LF)+50W(HF) | 250W(LF)+50W(HF) | 400W(LF)+50W(HF) | 500W(LF)+50W(HF) |
| DSP Module | LA DSP-100, 96 kHz, 24-bit DSP processor with preset modes: Live, DJ, Normal | |||
| Protection | Short circuit overheating, over-current | |||
| Controls | Power On / Off switch, DSP modes switch, line level, mic/line switch | |||
| Indicators | Power, signal, limit, DSP modes | |||
| Audio Input / Output | 1 * Combo XLR/Jack input 1 * XLR output |
2 * Combo XLR/Jack input 1 * RCA line input 1 * XLR output |
||
| Optional Funciton | Bluetooth | |||
| Power Supply | 100~130V 50/60HZ or 210~250V 50/60HZ | |||
