PXL-15SD2 15 Inch Active Bass Reflex With DSP Control
PXL-15SD2 15 Inch Active Bass Reflex With DSP Control
PXL-15SD2 15 Inch Active Bass Reflex With DSP Control
PXL-15SD2 15 Inch Active Bass Reflex With DSP Control
PXL-15SD2 15 Inch Active Bass Reflex With DSP Control
PXL-15SD2 15 Inch Active Bass Reflex With DSP Control

PXL-15SD2 15 Inch Active Bass Reflex With DSP Control

Model NO.:
PXL-15SD2
Delivery:
FOB
Minimum order quantity:
100 pieces
Supply Ability:
60,000 pieces / Month
Country of Origin:
Ningbo, China
Stock Time:
45 Days
15" subwoofer steel frame, 4" KSV voice coil, 100oz + Class-D amplifier 700W with 96 kHz, 24-bit DSP processor with LCD display







Model No. PXL-15SPXL-15SD2
Type15'' bass reflex, passive15'' bass reflex, active
Frequency Response (-6dB)50 Hz - 200 Hz
Max. SPL(1m, free space)120 dB
Impedance4Ohms
Transducer LF15"subwoofer Alu frame, 4"KSV voice coil, 100oz
Enclosure15mm plywood with
sand painting, Φ35
 stand adaptor
GrilleMetal grille with acoustic fabric
Amplifier/Class-D amplifier
Power Output (RMS)700W
DSP Module/LA DSP-200S, 96 kHz, 24-bit DSP processor with LCD display
Protection/Short circuit overheating, over-current
Controls/Power On / Off switch,
main level,
DSP modes switch,
phase switch
Indicators/Power, limit
Audio Input / OutputSpeakonLeft / Right XLR line input
Left / Right XLR line output
1 * XLR output
1 * XLR output highpass 120Hz
Power Supply100~130V 50/60HZ
210~250V 50/60HZ
